Global Compact Fluorescent Bulb
The global energy saving bulb is equipped with a diffusely scattering glass spherical or global cover.
The global series provide good light distribution, soft and flattering, yet bright enough for applying writing, reading and so on.
Model: YB-30
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Diameter: |
| 41mm |
| Base Type: |
| E26, E14, E27 |
| Cover: |
| Clear or Opal |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
C
(mm) |
Length
(mm) |
Carton meas.
(100 pcs) |
| YB-30 |
5 |
250 |
66 |
115 |
72.5*36.5*28cm |
| YB-30 |
7 |
350 |
66 |
115 |
72.5*36.5*28cm |
| YB-30 |
9 |
450 |
66 |
115 |
72.5*36.5*28cm |
Model: YB-31
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Diameter: |
| 52mm |
| Base Type: |
| E26, B22, E27 |
| Cover: |
| Clear or Opal |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
C
(mm) |
Length
(mm) |
Carton meas.
(50 pcs) |
| YB-31 |
9 |
450 |
70 |
120 |
38*38*27.5cm |
| YB-31 |
11 |
550 |
70 |
120 |
38*38*27.5cm |
| YB-31 |
13 |
650 |
70 |
120 |
38*38*27.5cm |
Model: YB-32
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Diameter: |
| 72mm |
| Base Type: |
| E26, B22, E27 |
| Cover: |
| Clear or Opal |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
C
(mm) |
Length
(mm) |
Carton meas.
(20 pcs) |
| YB-32 |
15 |
750 |
100 |
165 |
53.5*43*19.5cm |
| YB-32 |
20 |
1000 |
110 |
170 |
58.5*47*20cm |
| YB-32 |
24 |
1200 |
120 |
180 |
63.5*51*21cm |
Model: YB-33
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Diameter: |
| 73mm |
| Base Type: |
| E26, B22, E27 |
| Cover: |
| Clear or Opal |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
C
(mm) |
Length
(mm) |
Carton meas.
(20 pcs) |
| YB-33 |
15 |
750 |
100 |
175 |
53.5*43*20.5cm |
| YB-33 |
20 |
1000 |
110 |
180 |
58.5*47*21cm |
| YB-33 |
24 |
1200 |
120 |
185 |
63.5*51*21.5cm |
Model: YB-55
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Diameter: |
| 65mm |
| Base Type: |
| E26, B22, E27 |
| Cover: |
| Clear or Opal |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
C
(mm) |
Length
(mm) |
Carton meas.
(20 pcs) |
| YB-55 |
13 |
650 |
90 |
122 |
48.5*39*16cm |
| YB-55 |
15 |
750 |
90 |
122 |
48.5*39*16cm |
| YB-55 |
18 |
900 |
100 |
135 |
48.5*39*17.5cm |
| YB-55 |
20 |
1000 |
100 |
135 |
48.5*39*17.5cm |
|
