4U Compact Fluorescent Bulb
The 4U compact fluorescent bulb consists of a high performance electronic ballast and a 4U shaped trichromatic fluorescent lamp. The whole unit is compact and simple in construction and highly effective in light emitting, with soft light, excellent chromaticness and low heat-emission. Moreover, it can be instantly started even at a comparatively low temperature or voltage.
Model: YB-16
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E26, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(50 pcs) |
| YB-16 |
20 |
1000 |
60 |
155 |
65.5*33*19.5cm |
| YB-16 |
24 |
1200 |
60 |
160 |
65.5*33*20cm |
| YB-16 |
26 |
1300 |
60 |
165 |
65.5*33*20.5cm |
| YB-16 |
28 |
1400 |
60 |
170 |
65.5*33*21cm |
| YB-16 |
30 |
1500 |
60 |
175 |
65.5*33*21.5cm |
| YB-16 |
32 |
1600 |
60 |
180 |
65.5*33*22cm |
| YB-16 |
35 |
1750 |
60 |
185 |
65.5*33*22.5cm |
| YB-16 |
38 |
1900 |
60 |
185 |
65.5*33*22.5cm |
Model: YB-17
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E26, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(50 pcs) |
| YB-17 |
20 |
1000 |
60 |
157 |
65.5*33*19.5cm |
| YB-17 |
24 |
1200 |
60 |
162 |
65*33*20cm |
| YB-17 |
26 |
1300 |
60 |
167 |
65*33*20.5cm |
| YB-17 |
28 |
1400 |
60 |
172 |
65*33*21cm |
| YB-17 |
30 |
1500 |
60 |
177 |
65*33*21.5cm |
| YB-17 |
32 |
1600 |
60 |
182 |
65*33*22cm |
| YB-17 |
30 |
1750 |
60 |
187 |
65*33*22.5cm |
| YB-17 |
32 |
1900 |
60 |
187 |
65*33*22.5cm |
Model: YB-18
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E26, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(50 pcs) |
| YB-18 |
40 |
2000 |
72 |
220 |
77.5*39*26cm |
| YB-18 |
45 |
2250 |
72 |
225 |
77.5*39*26.5cm |
| YB-18 |
50 |
2500 |
72 |
225 |
77.5*39*26.5cm |
Model: YB-19
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E26, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(50 pcs) |
| YB-19 |
40 |
2000 |
72 |
210 |
77.5*39*25cm |
| YB-19 |
45 |
2250 |
72 |
215 |
77.5*39*25.5cm |
| YB-19 |
50 |
2500 |
72 |
225 |
77.5*39*25.5cm |
Model: YB-20
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E26, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
A
(mm) |
Length
(mm) |
Carton meas.
(20 pcs) |
| YB-20 |
60 |
3000 |
72 |
253 |
41*33*29.5cm |
| YB-20 |
65 |
3250 |
72 |
258 |
41*33*30cm |
| YB-20 |
70 |
3500 |
72 |
263 |
41*33*30.5cm |
Model: YB-40
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E26, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(100 pcs) |
| YB-40 |
13 |
650 |
49 |
117 |
56.5*28.5*30.5cm |
| YB-40 |
15 |
750 |
49 |
122 |
56.5*28.5*31.5cm |
| YB-40 |
18 |
900 |
49 |
127 |
56.5*28.5*32.5cm |
| YB-40 |
20 |
1000 |
49 |
132 |
56.5*28.5*33.5cm |
* Slim 4U compact fluorescent bulb and mini 4U energy saving lamp with slim & mini tube
Model: YB-44
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E26, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(100 pcs) |
| YB-44 |
20 |
1000 |
61 |
155 |
67*34*19.5cm |
| YB-44 |
24 |
1200 |
61 |
160 |
67*34*20cm |
| YB-44 |
26 |
1300 |
61 |
165 |
67*34*21cm |
| YB-44 |
28 |
1400 |
61 |
170 |
67*34*22cm |
| YB-44 |
30 |
1500 |
61 |
175 |
67*34*23cm |
| YB-44 |
32 |
1600 |
61 |
180 |
67*34*24cm |
| YB-44 |
35 |
1750 |
61 |
185 |
67*34*25cm |
| YB-44 |
38 |
1900 |
61 |
185 |
67*34*25cm |
Model: YB-52
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(100 pcs) |
| YB-52 |
11 |
550 |
50 |
125 |
57.5*29*33cm |
| YB-52 |
13 |
650 |
50 |
130 |
57.5*29*34cm |
| YB-52 |
15 |
750 |
50 |
135 |
57.5*29*35cm |
| YB-52 |
20 |
1000 |
50 |
140 |
57.5*29*36cm |
* Slim 4U compact fluorescent bulb and mini 4U energy saving lamp with slim & mini tube
Model: YB-53
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E14, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(50 pcs) |
| YB-53 |
35 |
1750 |
70 |
197 |
74*38*23.5cm |
| YB-53 |
40 |
2000 |
70 |
202 |
74*38*24cm |
| YB-53 |
45 |
2250 |
70 |
207 |
74*38*24.5cm |
Model: YB- 54
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| E40, B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(20 pcs) |
| YB-54 |
65 |
3250 |
88 |
300 |
48*38.5*34cm |
| YB-54 |
75 |
3750 |
88 |
310 |
48*38.5*35cm |
| YB-54 |
85 |
4250 |
88 |
320 |
48*38.5*36cm |
Model: YB- 57
| Supply Voltage: |
| 100-240V/50-60Hz |
| Color Temperature: |
| 2700K or 6400K |
| Base Type: |
| B22, E27 |
|
 |
|
|
|
| Model |
Wattage
(W) |
Luminous
Flux(lm) |
Diameter
(mm) |
Length
(mm) |
Carton meas.
(100 pcs) |
| YB-57 |
11 |
550 |
47 |
105 |
53.5*27*29cm |
| YB-57 |
13 |
650 |
47 |
110 |
53.5*27*30cm |
| YB-57 |
15 |
750 |
47 |
115 |
53.5*27*32cm |
| YB-57 |
18 |
900 |
47 |
125 |
53.5*27*34cm |
|
