Column Compact Fluorescent Bulb


The column compact fluorescent bulb is equipped with a diffusely scattering glass cylindrical cover giving off soft and uniform light.

The room can be made more inviting, comfortable and functional when you choose the styles of the bulb (also called energy saving lamp ).


Model: YB-6
Supply Voltage:
100-240V/50-60Hz
Color Temperature:
2700K or 6400K
Base Type:
E27, B22, E14



Model Wattage
(W)		 Luminous
Flux(lm)		 Diameter
(mm)		 Length
(mm)		 Carton meas.
(100 pcs)
YB-6 5 250 38 113 44.5*22.5*29cm
YB-6 7 350 38 123 44.5*22.5*31cm
YB-6 9 450 38 133 44.5*22.5*33cm
YB-6 11 550 38 143 44.5*22.5*35cm
YB-6 13 650 38 153 44.5*22.5*37cm
YB-6 15 750 38 163 44.5*22.5*39cm


Model: YB-34
Supply Voltage:
100-240V/50-60Hz
Color Temperature:
2700K or 6400K
Base Type:
E27, B22, E26



Model Wattage
(W)		 Luminous
Flux(lm)		 C
(mm)		 Length
(mm)		 Carton Meas.
(50 pcs)
YB-34 15 750 75 158 40.5*40.5*35cm
YB-34 20 1000 75 180 40.5*40.5*39cm

Model: YB-35
Supply Voltage:
100-240V/50-60Hz
Color Temperature:
2700K or 6400K
Base Type:
E26, B22, E27



Model Wattage
(W)		 Luminous
Flux(lm)		 C
(mm)		 Length
(mm)		 Carton Meas.
(50 pcs)
YB-35 15 750 65 158 35.5*35.5*35cm
YB-35 18 900 65 178 35.5*35.5*39cm
YB-35 20 1000 65 178 35.5*35.5*39cm

Model: YB-81
Supply Voltage:
100-240V/50-60Hz
Color Temperature:
2700K or 6400K
Base Type:
E27, E14



Model Wattage
(W)		 Luminous
Flux(lm)		 C
(mm)		 Length
(mm)		 Carton Meas.
(50 pcs)
YB-81 7 385 40 80 53.5*27.5*22cm
YB-81 9 495 40 85 53.5*27.5*24cm
YB-81 11 605 40 90 53.5*27.5*24cm
